Cloud MA60Media
Mixer Amplifier
Our Part No. 11106
Manufacturers Part No. MA60Media
Product end of line
Please note this product is EOL (End of Life) and no longer available from the manufacturer. We may still have stock or can recommend an alternative. Please contact us to discuss!
Product end of line
Description
The MA60Media is an exciting new development from Cloud Electronics, combining for the first time the proven versatility of Cloud mixer-amplifiers with the convenience of an on-board media player in a single compact (2U, half-rack width) unit, and at a very keen price point. The Media Player supports .MP3 or .WMA files directly from a USB device or SD memory card plugged into the front panel of the unit. All standard data rates and sampling frequencies are supported. A simple set of playback controls (ShufflePlay etc) is provided on the front panel with the least amount of user/error functionality. The MA60Media will find many applications in the Retail, Hospitality, Licenced Premises and other entertainment markets and is the most feature rich of the Utility Mixer/Amps on the market which also offers the best sound quality and the traditional Cloud reliability. Single Zone, 60w, 4Ω Output as Standard with Optional 50w, 70/100v Internal Transformer (CXL-50T)
Key features
- Four-input mixer-amplifier with integral 60w 4Ω mono power amplifier
- Optional 70/100v Internal Transformer (CXL-50T)
- Built-in digital music player supports .MP3 and .WMA files at all standard data rates/sample frequencies
- Gain trims on all inputs
- Electronically-balanced mic input
- 3.5 mm jack input (LINE 2) for MP3 player, laptop, etc.
- Overall HF & LF EQ adjustment
- Short-to-ground access connector or VOX-triggered paging on mic input
- Selectable LINE 4 priority over other music inputs
- Music Mute control input (NO or NC) for interface to emergency system
- Compatible with standard Cloud remote controls – RL-1 (music level) and RSL-4 (music level and source selection)
- Electronically-balanced pre-amp output
- Transformer-isolated auxiliary output with independent mic and music level control - for use with telephone MOH systems
- Aux output source selection (internal jumper) – fixed source or follow main output
- Dimensions (mm) - 213.0 wide x 88 high (2U) x 278 deep (+ connectors & knobs)
- Optional Rack Kits (RE-S & RE-L)
